Polyester-imide enameled Al wire 180 degree , EIW



Available builds Single Heavy
Code 2EIW/180 1EIW/180
Composition Copper，Aluminum and polyesterimide resin
Characteristic Excellent heat-shock resistance, high electrical properties and mechanical strength.
Application Class H motors and electrical appliances
Round wire Φ0.100-4.000mm
Temp. index 180
Test Cut-through Heat-shock  Flexility and adhesion  Continuity of insulation Solvent Resistance
Applicable specification IEC317 IEC851 GB6109 GB4074 JIS3202  JIS3003



Polyester-imide/Polyamide-imide

Available builds Single Heavy
Code 2EI/AIW/200 1EI/AIW/200
Composition Copper，Alumuinum and polyester-imide overcoated with polyamide-imide resin
Characteristic Good Thermal endurance resistance, chemical resistance, as well as excellent mechanical and electrical properties.
Application Class C motors, electrical appliance and refrigerant system.
Rectangular wire Thickness 1.00-4.00mm   Width 2.00-12.50mm
Round wire Φ0.100-4.000mm
Temp. index 200
Test Cut-through Excellent heat-shock resistance, high electrical properties and mechanical strength
Applicable specification IEC317 IEC851 GB6109 GB4074 JIS3202  JIS3003
