Portable Ground Earth Rod Set with Earthing Wire and Clamp
Structure: The flat spiral grounding line by wire end terminal, short, ground wire, wiring nose, bus route, the grounding end terminal (or) temporary grounding and grounding operation bar, etc. Line end and the grounding wire clip, high quality aluminum alloy die-casting clamp and two kinds of pure copper wire clip, and its matching fasteners by metal chrome plating treatment. Grounding bar operation USES electrical and mechanical strength are good imports of advanced epoxy resin, glass fiber is delicate. Short line and grounding line type of the multi-strand fine the annealed copper stranded wire is coated with a soft, high temperature resistant made of transparent insulation layer. Ground wire clamp and insulation lever connection points have fixity and detachable type two kinds, and for substation busbar and overhead conductors such as a variety of styles, user can choose according to actual need. Soft cooper cable is made of pure copper The resistance to the ground is as follows: the DC resistance measured between the wiring noses should be less than 0.79 m, 0.56 m, 0.40 m, 0.28 m, 0.21 m, 0.16 m, respectively, for various sections of 25mm2, 35mm2, 50mm2, 70mm2, 95mm2, 120mm2. Power frequency withstand voltage test of the operating rod, 10KV, 35KV, 63KV, 110KV, 220KV grounding rod respectively through 45KV, 95KV, 175KV, 220KV, 440KV to withstand voltage, keep one minute without breakdown. The 330KV and 500KV grounding rods should withstand voltage on 380KV and 580KV for five minutes without breakdown. Advantages 1. Anti-moisture. Nice looking. 2. Epoxy rod with light weight and high strength 3. Easy Maintenance; easy operation, flexibly structured 4.Good insulation performance Product Features Earthing rod: epoxy, with good insulation performance; the length is optional. The hook adopts light aluminum alloy compression casting, pole use the light epoxy manufacture, high strength, excellent ability of electric conduction. Baling wire uses electrolysis copper wire. The temperature scope for protective cover: ±40°C Cooper wire's cross section area: 10mm²/16mm² / 25 mm² / 35mm² /50 mm² /75mm²/90mm²/95mm²/120mm²/130mm²/150mm²; or customized. Copper wire : High voltage earthing copper wire Multiple roots is made of 99.95% purple copper , The overhead grounding wire is made of 99.95 copper. The multiple diameter is 0.2mm oxygen-free fine copper wire. Copper wire advantage : -----Hig purity 99.95% -----Standard production -----Free bending under minus 35 degrees -----Long surface life Earthing clamp's material: Aluminum or cooper Features: 1 .The operating head made of cooked aluminum (copper) --------High strength, strong and durable 2 .The operating stick is mechanically drawn using imported epoxy resin-------Lighter than traditional craftsmanship and more strength. 3. 99.95% standard copper wire + Transparent PVC skin. -Wear-resistant. -Easy to check. -Keep soft in extremely cold weather. -Extended service life. 4. Canvas carrying bag for easy to carry.
